Directed DS4+ Installation Manual page 18

Wire Information
Function Color
Lexus RX 400h 2006-2008
RX Lt. Green
TX Brown
Keysense Black
12V Red
Starter Blue
Ignition 1 Violet
Ignition 2 Green
Accessory Brown or Gray
Tach Black
Autolights Brown
Parking Lights Orange
Lock Brown
Unlock Gray
Brake Blue
Door Trigger Lt. Blue
Power Liftgate Violet
Pontiac Vibe 2008
RX Blue
TX Green
Keysense Blue/Black
12V White
Starter Red
Ignition 1 Black/White
Ignition 2 Black/Yellow
Accessory Blue/Red
Lock Green
Unlock Blue/Yellow
Tach Black
Brake Green/White
Trunk Release Blue/White
Door Trigger Red/Yellow
Scion tC 2005-2010
RX Yellow
TX Red
12V Red
Starter 1 Black
Starter 2 Green
Ignition 1 Blue
Ignition 2 Yellow
Accessory Gray
Tach Black
Parking Lights Brown
Lock Green or Blue
Unlock Violet or Pink
Brake Blue
Trunk Release Orange
Door Trigger Blue
Keysense Black
18
Pin Polarity Location
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
2 (-) Key warning switch.
7 (+) Ignition switch.
8 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
3 (+) Ignition switch.
9 AC OBDII.
19 Cut Headlight switch.
18 (-) Headlight switch.
4 (-) Power window master switch.
14 (-) Power window master switch.
3 (+) Bottom of fuse box.
5 (-) Right side of dash fuse box.
3 (-) Power liftgate switch.
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
2 (-) Key warning switch.
1 (+) Ignition switch.
4 (+) Ignition switch.
6 (+) Ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
6 (-) Drivers kick panel.
7 (-) Drivers kick panel.
5 AC Body ECU behind glove box.
1 (+) Brake pedal switch.
2 (-) Trunk release switch.
N/A (-) Drivers "A" pillar.
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
7 (+) Ignition switch.
8 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
3 3 Ignition switch.
9 AC OBDII.
14 (-) Headlight switch.
15 (-) Drivers kick panel.
14 (-) Drivers kick panel.
9 (+) Drivers kick panel.
12 (-) Drivers kick panel.
2 (-) Dash fuse box.
26 (-) Dash fuse box.
Connector Information
Color
Black
Black
White
White
White
White
White
White
Black
White
White
White
White
White
White
Black
Black
Black
Black
White
White
White
White
White
White
White
White
White
White
N/A
Black
Black
White
White
White
White
White
White
White
White
White
White
White
Gray
White
White
© 2017-11-27 Directed. All rights reserved.
Pins Ref.
7 A
7 A
4 B
8 B
8 B
8 B
8 B
8 B
16 C
20 D
20 D
20 E
20 E
12 G
12 G
4 I
7 A
7 A
2 B
6 B
6 B
6 B
6 B
6 B
10 F
10 F
31 G
4 H
5 I
N/A K
7 A
7 A
8 B
8 B
8 B
8 B
8 B
8 B
16 C
17 D
20 F
20 F
30 F
12 F
6 G
32 G
DS4+ TL11
