Directed DS4+ Installation Manual page 26

Wire Information
Function Color
Toyota Venza 2009
RX Lt. Green
TX Brown
Keysense Brown
12V Blue
Starter 1 Red
Starter 2 Green
Ignition 1 Green
Ignition 2 Red
Accessory Green
Tach Gray
Autolights Brown
Parking Light Red
Lock Brown
Unlock Gray
Door Trigger Pink
Brake Lt. Green or Blue
Power Liftgate Brown
Toyota Yaris 2006-2011
RX Green
TX Violet
12V Yellow
Starter Black
Ignition 1 Pink
Ignition 2 Green
Accessory White
Tach Lt. Green or Tan
Parking Lights White
Lock Brown
Unlock Green
Keysense Yellow
Door Trigger Pink
Brake Green or Violet
26
Pin Polarity Location
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
1 (-) Key warning switch.
7 (+) Ignition switch.
8 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
3 (+) Ignition switch.
6 AC OBDII.
19 Cut Headlight switch.
18 (-) Headlight switch.
11 (-) Drivers kick panel.
8 (-) Drivers kick panel.
5 (-) Dash fuse box.
3 (+) Dash fuse box.
4 (-) Power liftgate switch.
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
4 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
1 (+) Ignition switch.
2 (+) Ignition switch.
9 AC OBDII.
13 (-) Headlight switch.
7 (-) Drivers kick panel.
8 (-) Drivers kick panel.
7 (-) Dash fuse box.
2 (-) Dash fuse box.
12 (+) Dash fuse box.
Connector Information
Color
Black
Black
White
White
White
White
White
White
White
Black
White
White
White
White
White
White
Black
Black
Black
White
White
White
White
White
White
White
White
White
White
White
White
© 2017-11-27 Directed. All rights reserved.
Pins Ref.
7 A
7 A
2 B
8 B
8 B
8 B
8 B
8 B
8 B
16 C
20 D
20 D
18 F
18 F
12 G
25 G
5 I
7 A
7 A
8 B
8 B
8 B
8 B
8 B
16 C
13 D
20 F
20 F
14 G
6 G
30 G
DS4+ TL11
