Directed DS4+ Installation Manual page 20

Wire Information
Function Color
Toyota Camry 2003-2006
RX Green/White
TX Blue/Yellow
Keysense Blue
Door Trigger Green/Red
12V White/Red
Starter 1 Black/White
Starter 2 Black/Yellow
Ignition 1 Black/Red
Ignition 2 Black/Yellow
Accessory Blue/Red
Autolights White
Parking Lights Red
Trunk Release White/Blue
Lock Blue/Yellow
Unlock Blue
Brake Green/White
"Black/Orange (V6) or
Tach
White (V4)"
Toyota Corolla 2005-2008
RX Lt. Blue or Pink
TX Tan or Green
Keysense Blue/Black
12V White
Starter Red
Ignition 1 Black/White
Ignition 2 Black/Yellow
Accessory Blue/Red
Parking Lights Green/White or Green
Lock Green
Unlock Blue/Yellow
Brake Green/White
Door Trigger Red/Yellow
Tach Black
20
Pin Polarity Location
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
2 (-) Key warning switch.
1 or 6 (-) Ignition key cylinder light.
7 (+) Ignition switch.
8 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
3 (+) Ignition switch.
12 Cut Headlight switch.
14 (-) Headlight switch.
5 5-wire Drivers kick panel.
7 (-) Drivers kick panel.
2 (-) Drivers kick panel.
15 (+) Dash fuse box.
16 or
AC Right of steering column or behind cluster
11
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
2 (-) Key warning switch.
1 (+) Ignition switch.
4 (+) Ignition switch.
6 (+) Ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
13 (-) Headlight switch.
6 (-) Drivers kick panel.
7 (-) Drivers kick panel.
N/A (+) Drivers kick panel, harness to rear.
6 (-) Rear of drivers fuse box.
5 AC ECM behind glove box.
Connector Information
Color
Black
Black
Blue
Gray or
Black
White
White
White
White
White
White
White
White
White
White
White
White
White
Black
Black
White
White
White
White
White
White
White
White
White
N/A
Gray
Black
© 2017-11-27 Directed. All rights reserved.
Pins Ref.
7 A
7 A
2 B
2 or
B
6
8 B
8 B
8 B
8 B
8 B
8 B
17 D
17 D
12 F
20 F
20 F
20 G
22
L or
or
M
40
7 A
7 A
2 B
6 B
6 B
6 B
6 B
6 B
13 D
10 F
10 F
N/A F
6 G
31 G
DS4+ TL11
