Directed DS4+ Installation Manual page 24

Wire Information
Function Color
Toyota Sienna 2004-2010
RX Yellow
TX Yellow/Red
Keysense Blue/Black
12V White/Red
Starter Black/Yellow
Ignition 1 Black
Ignition 2 Black/Yellow
Accessory Pink
Autolights Violet
Parking Lights Green/Black
Lock Lt. Green
Unlock Blue
Red/Green (front dome
Door Trigger light) and Red/White
(rear dome light)
Power Liftgate Yellow/Red
Green/Yellow or Green/
Brake
White
Tach Black/Orange
Toyota Solara 2004-2009
RX Yellow or Green/White
Yellow/Red or Blue/
TX
yellow
Keysense Blue
12V White/Red
Starter 1 Black/White
Starter 2 Black/Yellow
Ignition 1 (coupe) Red/Black
Ignition 1 (convertible) Black/Red
Ignition 2 (coupe) Black/Yellow
Ignition 2 (convertible) Blue
Accessory Blue/Red
Tach Black/Ornage
Autolights White
Parking Lights Red
Trunk Release White/Blue
Lt.Green (coupe) or Blue/
Lock
Yellow (convertible)
Unlock Blue
Door Trigger Green/Red
Brake Green/White
24
Pin Polarity Location
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
2 (-) Key warning switch.
5 (+) Ignition switch.
4 (+) Ignition switch.
6 (+) Ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
12 Cut Headlight switch.
14 (-) Headlight switch.
5 (-) Drivers kick panel.
7 (-) Drivers kick panel.
10 Junction connector, left of dash fuse box. Isolate the front
(-)
& 3 and rear dome lights with diodes.
10 (-) Left of dash fuse box.
21 (+) Dash fuse box.
37 AC Behind insturment cluster
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
2 (-) Key warning switch.
7 (+) Ignition switch.
7 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
4 (+) Ignition switch.
3 (+) Ignition switch.
9 AC OBDII.
12 Cut Headlight switch.
14 (-) Headlight switch.
11 5-wire Drivers kick panel
18 (-) Drivers kick panel.
2 (-) Drivers kick panel.
5 (-) Dash fuse box.
13 (-) Dash fuse box.
Connector Information
Color
Black
Black
White
White
White
White
White
White
White
White
White
White
White
White
White
White
Black
Black
White
White
White
White
White
White
White
White
White
Black
White
White
White
White
White
White
White
© 2017-11-27 Directed. All rights reserved.
Pins Ref.
7 A
7 A
4 B
6 B
6 B
6 B
6 B
6 B
17 D
17 D
18 F
18 F
14 G
22 G
30 G
40 M
7 A
7 A
4 B
8 B
8 B
8 B
8 B
8 B
8 B
8 B
8 B
16 C
17 D
17 D
18 F
20 F
20 F
12 G
14 G
DS4+ TL11
