Directed DS4+ Installation Manual page 21

Wire Information
Function Color
Toyota FJ Cruiser 2007-2009
RX Pink/Green
TX Lt. Green/Red
12V Blue/Black
Starter 1 Green/Black
Starter 2 Black/White
Ignition 1 Black/Red
Ignition 2 Blue/Yellow
Accessory White/Green
Tach Black/White
Lock Blue
Unlock Pink
Brake Green/Yellow
Door Trigger White
Trunk Release Blue/Yellow
Keysense Green/Yellow
Parking Lights Green
Toyota Highlander 2004-2007
RX Gray
TX White
Door Trigger Green
Keysense Green
12V Yellow
Starter 1 Black/White
Starter 2 Black
Ignition 1 Gray
Ignition 2 Green
Accessory Blue
Tach Black
Autolights Pink
Brake Green
Lock
Unlock
21
Pin Polarity Location
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
7 (+) Ignition switch.
8 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
3 (+) Ignition switch.
9 AC OBDII.
6 (-) Drivers kick panel.
8 (-) Drivers kick panel.
16 (+) Bottom of dash fuse box.
8 (-) Dash fuse box.
13 5-wire Back door ECU in tailgate.
14 (-) Right side of dash fuse box.
8 (-) Right side of dash fuse box.
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
1 or 6 (-) Ignition key cylinder light.
2 (-) Key warning switch.
7 (+) Ignition switch.
8 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
3 (+) Ignition switch.
9 AC OBDII.
12 Cut Headlight switch.
6 (+) Drivers kick panel.
See Tech Doc 1070 on www.directechs.com
See Tech Doc 1070 on www.directechs.com
Connector Information
Color
Black
Black
White
White
White
White
White
White
White
White
White
White
White
White
White
White
Black
Black
Gray or
Black
White
White
White
White
White
White
White
Black
White
White
© 2017-11-27 Directed. All rights reserved.
Pins Ref.
7 A
7 A
8 B
8 B
8 B
8 B
8 B
8 B
16 C
18 F
18 F
16 G
20 G
25 G
26 G
26 G
7 A
7 A
2 or
B
6
4 B
8 B
8 B
8 B
8 B
8 B
8 B
16 C
17 D
14 F
DS4+ TL11
