Type - Directed DS4+ Installation Manual

Type 2

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
Transponder Key Amplier
(black 7-pin ignition connector)
7 6
Headlight Switch
(white 13-pin conn.)
2 1
4
3
13 1 1 10 9 8 7 5
12
6
(-) Parking Lights: White, pin 13
12
Data RX: Green, pin 4
5 4 3 2 1
Data TX: Violet, pin 5
Refer to the Vehicle Wiring
Reference Chart for wire
and connector details.
HS CAN High: Violet, pin 6
OBDII Plug
1 8
Black Connector
9 16
HS CAN Low: White, pin 14
(-) Parking Light Output: Lt.Green/Black: 1
Siren
Hood Pin
Ignition Switch
(+) Starter Output (Car Side): Violet: 7
1 2 3 4
5 6 7 8
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
Data RX: Orange/Black: 7
Data TX: Yellow/Black: 8
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
(+) 12V Input: Red: 6 & 12
Positioning
(-) Ground: Black: 10
(+) 12V Input: Red/Black: 2
(+) 12V Input: Red: 5
Starter Input (Key Side): Green: 6
(+) Accessory Output: Orange: 8
Slide
(+) 12V Input: Red/White: 9
to open
(+) Ignition Input/Ouput: Pink: 10
It is important to check that the
fuses are positioned correctly.
© 2017-11-27 Directed. All rights reserved.
).
DS4
DS4
DS4+
DS4+ TL11
