Directed DS4+ Installation Manual page 25

Wire Information
Function Color
Toyota Tacoma 2004-2010
RX Pink/Green
TX Lt. Green/Red
Keysense Green/Black
12V White/Red
Starter 1 Green/Black
Starter 2 Black/White
Ignition 1 Black/red
Ignition 2 Bue/Yellow
Accessory White/Green
Tach Black/White
Parking Light Green
Lock Violet
Unlock Green/Black
Brake Blue
Door Trigger Blue
Toyota Tundra 2007-2010
RX Lt. Green
TX Blue
Starter Green
Ignition 1 Black
Ignition 2 Lt. Green
Accessory Gray
Keysense Gray
Tach White
Door Trigger Blue
Lock Lt. Blue
Unlock Pink
Autolights Green
12V Black
Parking Light Oranger or Tan
Brake Tan
25
Pin Polarity Location
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
1 (-) Key warning switch.
5 (+) Ignition switch.
7 (+) Ignition switch.
3 (+) Ignition switch.
6 (+) Ignition switch.
1 (+) Ignition switch.
2 (+) Ignition switch.
9 AC OBDII.
18 (-) Headlight switch.
4 (-) Drivers kick panel.
8 (-) Drivers kick panel.
13 (+) Dash fuse box.
9 (-) Dash fuse box.
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
1 (+) Ignition switch.
2 (+) Ignition switch.
1 (-) Key warning switch.
9 AC OBDII.
10 (-) Interior light switch on dash.
14 (-) Drivers kick panel.
16 (-) Drivers kick panel.
21 Cut Body ECU on dash fuse box.
1 (+) Dash fuse box.
23 (-) Body ECU on dash fuse box.
1 (+) Brake pedal switch.
Connector Information
Color
Black
Black
White
White
White
White
White
White
White
White
White
White
White
White
Black
Black
Black
White
White
White
White
White
White
Black
Blue
Blue
White
White
White
Blue
© 2017-11-27 Directed. All rights reserved.
Pins Ref.
7 A
7 A
2 B
8 B
8 B
8 B
8 B
8 B
8 B
16 C
20 D
10 F
10 F
13 G
13 G
7 A
7 A
8 B
8 B
8 B
8 B
2 B
16 C
10 D
18 F
18 F
26 G
1 G
26 G
4 H
DS4+ TL11
