Canon imagePRESS C7010VPS Operating Information Manual page 265

#
IMPORTANT
If the printer is in the sleep mode, you may not be able to open the paper tray even
if you press the open button. In this case, press the control panel power switch to re-
activate the machine, and then press the open button.
Load tabs via the tab feeder
Press and release the button on the paper tray in which you want to load tab paper, and
1.
pull out the paper tray until it stops. When the inside lifter automatically descends to the
paper loading position, lift the paper holder plate, and remove all of the remaining paper.
Squeeze the lever on the rear guide as shown below, and slide the rear guide to the left as
2.
far as it will go.
Unlock the lever of the size change plate.
3.
Load tabs via the tab feeder (optional)
Chapter 9 - Paper, toner, and staples 265
