Internal view: the imaging unit (marking unit)
8
6
5
Main parts of the imaging unit (marking unit)
1
2
3
4
5
Component
Fusing unit
(Fixing unit)
Power cord
Power supply unit
7
4
Component
Toner unit
Intermediate transfer belt
Feeding unit
Skew correction roller
Test button
Function
The engine module contains paper
trays that contain the media that will
be printed.
Supplies the power from AC outlet
to the main unit and ADF.
Provides the power to the imaging
unit and fusing unit.
1
2
3
#
Function
Gives access to the toner bottles.
Transfers the toner to the paper.
Receives paper and can be opened to
remove jammed paper.
Compensates paper skewing or disper-
sion of side edge.
Located on the back side of the
power supply unit. Press this button
to periodically test the circuit breaker.
