NOTE
The spectrophotometer for calibration is not illustrated.
Optional paper modules
Input options
9
10
Component
Automatic Document Feeder
(Feeder DADF-R1)
Optional
Main unit
Integrated paper trays
Toner compartment cover
Waste toner tray
#
Component
Left-hand paper module
(POD Deck-A1)
Right-hand paper module
(Secondary POD-Deck-A1)
Overview of the machine configuration
Function
The automatic document feeder is
used to copy and scan sets of 1-sided
and 2-sided documents.
The main unit contains the compo-
nents that print the media. Access to
the main unit is only required when
a paper jam occurs or when mainte-
nance is required.
The main unit consists of the follow-
ing main parts.
Imaging unit (right-side)
(Marking unit)
Fusing unit (left-side)
(Fixing unit)
Power supply unit
The engine module contains paper
trays that contain the media that will
be printed.
Gives access to the toner bottles.
Gives access to the waste toner con-
tainer.
Function
The additional paper module has
paper trays that contain the media
that will be printed.
You can add a secondary paper
module to increase the media input
capacity.
Chapter 2 - Main parts 17
