2.3 System function

2.3.1 Self-diagnosis
Diagnose CPU, memory, LCD, I/O interface, parameter state, coordinates and processing program
comprehensively every time the system is started or reset; diagnose power supply, principal axis, limit and I/O
ports in real-time during operating.
2.3.2 Compensation
Automatic reverse clearance compensation
Automatic tool length compensation
Automatic tool radius compensation
Automatic tool radius biasing and automatic tool tip transition
2.3.3 Abundant instruction system
Scaling instruction
Mirror processing instruction
Tool biasing instructions
Program cycle, program skip, program shift, program transfer, different end processing modes, macro
definition and program management instructions
Fixed-point instructions: starting point, setting point, etc.
Linear, arc and spiral interpolation instructions
Six workpiece coordinate systems, nine extension coordinate systems and one reference point
2.3.4 Full Chinese menu operation & full screen edit
4640/4620 CNC system uses cascading menu structure and full Chinese operation to ensure simple
operation and visibility.
2.3.5 Abundant error-correction functions
Point out the nature and correct the errors in operation.
2.3.6 Program exchange between CNC system and PC
Perform CAD/CAM/CAPP auxiliary programming with abundant software in PC, and then transmit CNC
program to the system through communication interface (USB disk, RS232 interface), or transmit the
programs from the system to PC.
2.4 System operating condition
Operating voltage
Operating temperature
Optimum operating temperature
Operating humidity
Optimum operating humidity
Storage temperature
Storage humidity
Operating environment
24V DC (with filter)
0℃— 45℃
5℃— 40℃
10%——90% (no condensing)
20%——85%
0℃—50℃
10%——90%
No excessive dust, acid, alkali, corrosive and explosive gases, no strong
electromagnetic interference
2. Program saving & editing
