3.3 System menus

CNC46XX system uses cascading menu structure. You can press the following keys to operate the menus.
Press a key to show the corresponding content in the bottom of the LCD.
Key in the left: Return to previous menu
Key in the right: Turn pages to show other menus of same level
The main menus of the system include [Monitor], [Edit], [Parameter], [Coordinate] and [Diagnosis]. Each
main menu contains several submenus, which are shown below:
[Monitor]
[Edit]
- 8 -
[Position]
[Absolute Position]
[Relative Position]
[Comprehensive
P iti ]
[Track]
[Preview]
[Select Plane]
[MDI]
[Program Edit]
[File]
3. Program saving & editing
