Adtech ADT-CNC4620 Maintenance Manual page 57

Adtech CNC Technology Co., Ltd.
009
X FastSpeed(mm/min)
010 FastSpeed(mm/min)
011 Z FastSpeed(mm/min)
012 4 FastSpeed(mm/min)
013
XStartupSpeed(mm/min)
014 YStartupSpeed(mm/min)
015 ZStartupSpeed(mm/min)
016 4StartupSpeed(mm/min)
017
X Acceleration(Kpps)
018 Y Acceleration(Kpps)
019 Z Acceleration(Kpps)
020 4 Acceleration(Kpps)
Range
Unit
Authority
Default
Effective time
Note
021
X Soft PosLimit+(mm)
022 X Soft PosLimit-(mm)
023 Y Soft PosLimit+(mm)
024 Y Soft PosLimit-(mm)
025 Z Soft PosLimit+(mm)
026 Z Soft PosLimit-(mm)
027 4 Soft PosLimit+(mm)
028 4 Soft PosLimit-(mm)
Range
Unit
Authority
Default
Effective time
Note
: 1~9999, 1~9999, 1~8000
: mm/min,mm/min,mm/sec
: Operation admin or higher
: 3000,200,1500
: Instant
: This parameter is the trapezoid acceleration/deceleration setting and used
for GOO instruction
About start speed, 1-2 rotation motor speed is recommended for step
motor; as above, the machine tool moves 5mm when the motor rotates
one cycle, and the speed is 5-10mm/sec (300-600mm/min). For servo
motor, the start and stop shouldn't have vibration. If this speed is too high,
it will cause vibration during motion, and the step motor will be out of
step.
The acceleration and start speed also affect manual speed, home speed,
etc.;
: -9999~9999
: mm
: Operation admin or higher
: Maximum positive/negative value
: Instant
: Generally, the machine tool has hard limit signal. In this case, software
limit isn't required. Please set the positive limit to +9999.999, and
negative limit to -9999.999.
If hard limit switch isn't installed, please use soft limit, which uses
machine tool coordinate system as the base point. Positive limit and
negative limit are subject to actual distance (unit: mm).
Since soft limit decelerates and stops at the limit point, it may exceed the
set distance, which depends on acceleration time and speed. Please keep
certain margin when setting this parameter.
11. System parameters
- 53 -
