10.

System maintenance

10.1 Restart
⑴ In the main menu, press [Edit] to enter the program interface;
⑵ Press [File] to enter the file interface;
⑶ Press [Reset] and the system asks whether restart or not;
⑷ Press [OK] to restart the system.
10.2 System upgrade
The step of copying upgrade program with USB disk follows:
⑴ In the main menu, press [Edit] to enter the program interface;
⑵ Press [File] to enter the file management interface;
⑶ Insert the USB disk, select the USB disk symbol in the root directory; after reading successfully, the
system enters the USB directory automatically;
⑷ Move cursor to the upgrade file ADTROM.BIN, select [Copy], enter ADT directory in disk D and
paste;
⑸ Select the second upgrade file NC_RES.NC; skip this step if the file doesn't exist. Also select Copy,
enter disk D, and paste in directory ADT.
(6) After upgrading, enter BIOS, select USB in [Boot-up mode], and restart the system to take effect.
(7) Enter System Info in Diagnosis menu to view the system version and compilation date, and check
whether the upgrade is successful.
10.3 Reset
⑴Select the edit mode;
⑵ In the main menu, press [Parameter] to enter the parameter interface;
⑶ Press [Management] key to enter management parameter interface;
⑷ Move cursor to "006 Reset all parameters";
⑸ Press [EOB], the system confirms, restores the default parameters and restarts automatically.
10.4 Parameter backup and restore
⑴ Select the edit mode;
⑵ In the main menu, press [Parameter] to enter the parameter interface;
⑶ Press [Management] key to enter management parameter interface;
⑷ Move cursor to 007 or 008, and select corresponding operation menu;
⑸ Press [EOB], the system confirms, and performs backup or restore operation;
(6) The backup operation will generate the SYSCONF.BAK file in the root directory of disk D. Please
save this file for backup in the future.
(7) For restore operation, also save the SYSCONF.BAK file in the root directory of disk D. The system
will recognize this file automatically in the process of restoring.
10.5 Entering BIOS
(1) If the system has irreversible error and can't be started, please enter BIOS to upgrade and maintain the
program;
(2) To enter BIOS, press the [Cancel] key after the controller is electrified and before the application is
started; after entering, a blue background interface pops up. If the BIOS requires password, a prompt pops up.
Please type the password to enter the BIOS.
(3) Enter BIOS to perform operations such as format disk C, D, and copy files from USB disk to upgrade;
