9.9 Controller diagnosis interface (diagnosis)

The diagnosis interface is used to display the hardware interfaces and system info, including alarm, input,
output, DA diagnosis; press [Diagnosis] to enter the diagnosis interface.
The diagnosis interface follows:
[Diagnosis/DGNOS]
Alarm interface
Display the alarm of the system after power on, including 15 alarm records.
IO diagnosis interface
IO diagnosis allows entering at any moment. You can check current IO state of the system. In manual
mode, press the direction keys to select corresponding IO, and press EOB to control the output manually.
DA diagnosis interface
Correct the output voltage of two lines DA voltage module for testing; press the direction keys to output
corresponding voltage directly, input the actually measured voltage to corresponding gear position; when
transferring control instructions of principal axis, the system will correct according to correction value.
System info
The system info shows basic information of current system, and is used to mark current software version,
hardware version, upgrade info, etc. In this interface, you can follow the prompt to perform operations.
9.10 Macro variable view interface (macro variable)
This is the variable register view menu of macro function. In this menu, you can turn pages to view the
macro variables, or enter values to variable register directly in edit mode.
To enter macro variable view interface:
[MONITOR]
The macro variable menu has eight levels, as below:
Local variable
#100~#199
#500~#599
#600~#699
#700~#799
#800~#899
#900~#999
Process variable
In the variable interfaces of different levels, you can check the corresponding variable number. Local variable has five
levels totally, and shows the variables of current working layer by default. To view a specific layer, please enter local
variable submenu, and then select according to layers.
Alarm
Input
Output
DA
System Info
Macro Variable
