1033 : 4 - direction machine limit
1034 : 4 + direction machine limit
1035 : Z - direction machine limit
1036 : Z + direction machine limit
1037 : Y - direction machine limit
1038 : Y + direction machine limit
1039 : X - direction machine limit
1040 : X+ direction machine limit
The system has corresponding limit alarm. Please check corresponding limit sensor point or parameters.
If hard limit occurs, and the appearance of the sensor point doesn't has any problem, enter the diagnosis
mode in manual mode and check the state of the input port in diagnosis mode. If the state is valid,
please eliminate in sequence. Pull out the input IO cable and check whether the sense disappears. If yes,
please check the circuit. If the problem still exists, the internal optocoupler is broken. Please contact the
supplier.
1041 : Emergency stop
Emergency stop button of the handheld box interface is valid.
External emergency stop 2 input is valid; check whether IO assignment has conflict or interference.
Search for corresponding function ports in IO configuration, and then check in input diagnosis.
1042 : X Sevor driver alarm
1043 : Y Sevor driver alarm
1044 : Z Sevor driver alarm
1045 : 4 Sevor driver alarm
Servo alarm; if the servo doesn't alarm, parameter P2.001~004 setting and actual servo alarm level may
be reverse. Please modify the parameters.
The corresponding function ports are IN34~37, which can be checked in input diagnosis.
1046 : Axis's physical line redefine
Interface axis No. set by parameter P2.45~P2.49 is specified repeatedly
1047 : spi no to home
1048 : workpiece no lock
1049 : safe signal can't detect
1051 : air no enough
1052 : chuck signal alarm detect

7.3 Alarm processing

If alarm occurs, please refer to the alarm code to confirm the failure reason.
When alarm occurs, if the system isn't reset, the alarm will constantly prompt no matter whether the
alarm still exists, so as to avoid the conditions that false alarm causes system suspended, but can't
find the reason.
If the error is caused by data setting, modify the data, and then press [Reset] to clear the alarm info.
