Adtech ADT-CNC4620 Maintenance Manual page 62

Adtech CNC Technology Co., Ltd.
Unit
Authority
Default
Effective time
Note
067 Pressure Signal ELevel
Range
Unit
Authority
Default
Effective time
Note
073 SpindleAlarm ELevel
074 TransduserAlarm ELevel
068 ChuckSignal ELevel
Range
Unit
Authority
Default
Effective time
Note
069 OilPressure Open(min)
070 OilPressure Keep(sec)
071 OilPressureOut Freq(Hz)
Range
Unit
Authority
Default
Effective time
Note
072 OilInspect ELevel
Range
Unit
Authority
Default
Effective time
Note
- 58 -
: LOGIC VOLTAGE LEVEL
: Operation admin or higher
: 0
: Instant
: Set the effective voltage level of the system safety signal. The source of
safety signal can be customized by the user, and generally may be
electric cabinet door and similar sensitive occasions. If there are several
insecure places, please connect the signals in parallel to safety signal test
pin of the system.
Considering the convenience of maintenance, safety signals are checked
only when the system starts processing, and won't prompt in idle state.
: 0~1
: LOGIC VOLTAGE LEVEL
: Operation admin or higher
: 0
: Instant
: Set the effective voltage level of system air pressure alarm
Both air pressure alarm and emergency stop alarm are effective globally.
: 0~1
: LOGIC VOLTAGE LEVEL
: Operation admin or higher
: 0
: Instant
: The above alarms are checked while the system is running. The system
alarms once the test is valid.
This port is affected by IO configuration.
:
:
: Operation admin or higher
: 0
: Instant
: Set the schedule start and holding time of the automatic oil pump of the
system
Schedule open setting is that the oil pump outputs (OUT10) when the
timing reaches specified value after the system starts and times.
Output signal stops keeping for the seconds specified by P1.070 (reverse
phase).
Output signal follows the hertz specified by P1.071 in working state, and
used for oil supply devices. If it is set to 0, the system will keep low
output level.
: 0~1
: LOGIC VOLTAGE LEVEL
: Operation admin or higher
: 0
: Instant
: Lubricant pressure test is performed automatically when the lubricant
output of the system completes.
The system alarms immediately if no oil pressure in place signal is
detected after lubricant output.
This port is affected by IO configuration.
