Adtech ADT-CNC4620 Maintenance Manual page 8

Adtech CNC Technology Co., Ltd.
Function
Feeding
Manual
Interpolation
Operating mode
Testing function
Coordinate system and
pause
Safe functions
Program storage
Program edit
Display
M, S, T function
Compensation function
Other functions
- 4 -
Name
Fast feeding speed
Per minute
Feeding speed range
Per rotation
Automatic acceleration/deceleration
Feeding speed rate
Continuously manual feeding,
Returning to reference point manually
Single step/handwheel function
Positioning, linear interpolation,
interpolation
MDI, auto, manual, single step, edit
Test run, single program section, Handwheel
Pause (sec/ms)
Coordinate system setting
Automatic coordinate system setting
Soft & hard limit check
Emergency stop
Program storage capacity, storage quantity
Program edit
Program No., sequence
character retrieval
Decimal point programming
800×480 pixels 7" LCD
Position screen, program edit
Tool compensation setting, alarm display
Handwheel test, diagnosis screen
Parameter setting, graphic simulation
Auxiliary function
Principal axis function
Tool function
Tool compensation memory
Reverse clearance compensation
Measurement centered
Automatic tool regulator
Specify arc radius R/center position
Electronic gear ratio
X axis, Y axis, Z axis, A axis: 9999
mm/min (maximum)
1~9999mm/min
1~500rpm
Yes
10~150%
Yes
All control axes return to reference point
simultaneously
(allow setting order of priority)
Yes
arc G00, G01, G02/G03
Yes
Yes
G04 X/P_
G92 (M series)
G50 (L series)
Yes
Yes
Yes
Capacity: 60MB
100 work areas
No limit on processing file quantity
Insert, modify, delete, cancel
No., address, Yes
Yes
Yes
M code
S0-S15 (gear position control)
S15-S99999 (analog)
T code
30 tools length, radius compensation
Yes
Yes
Yes
Yes
2. Program saving & editing
Specification
