11.6 Principal axis parameters (P5.)

001 Spi.Alarm ELevel
002 Spi.Reset ELevel
003 Spi.ECZ Home Enable
004 Spi.ECZ Elevel
005 Spi. Limit+ Enable
006 Spi. Limit- Enable
007 Spi.Limit Elevel
008 Spi.Pulse Mode
009 Spi.Pulse Logic Mode
010 Spi.HomeDect ELevel
011 Spi.ExtHome Check En
012 Spi.Round Setting
014 Spi.ZeroOffset(p)
015 Spi.PulseLogic Level
016 Spi.Rolling Display Usage
017 Spi.Max Acc(Kpps)
018 Spi.Ext HomeDir
019 Spi.Servo HomeDir
021 Spi.Home Speed(rpm)
Range
Unit
Authority
Default
Effective time
Note
013 Spi.Encode bits(p)
Range
Unit
Authority
Default
Effective time
Note
020 Spi.Max Speed(rpm)
Range
Unit
Authority
Default
Effective time
Note
:
:
: Operation admin or higher
:
:
: Servo principal axis parameters are same as common positioning axis
parameters. If only the principal axis is controlled with servo port, you
can set the number according to axis parameters.
: 64~9999
: None
: Operation admin or higher
: 2500
: Instant
: The received wire number of the encoder when the principal axis rotates
one circle;
Same as common axis encoder, it can only receive AB phase pulse, and
thus the wire number of the encoder must be pulses of one circle divided
by 4.
This parameter will affect G74 and G84 tap instructions. Please set it
properly.
: 1~30000
: None
: Operation admin or higher
: 24000
: Instant
: This setting is used to calculate the analog output of the controller, and
suppose that the analog of variable frequency control is in linear control
mode;
This method is to set the rotation to this parameter according to the
variable frequency rotation corresponding to analog 10V, and transfer the
11. System parameters
