7. Alarm and self- diagnosis function

The system has several levels, and the alarm numbers also have different type, as follow:
0~1023:
1024~2048:
7.1 NC program execution alarm
0000 Reset
:
0001 : Prog No End
0004 M6Tx Abort
:
0005 : Tool Invalid
0006 : G Program Repeat Error
0007 G Program Number Error
:
0008 : G7X8X Instruction Run Error
0009 Program Abend
:
0010 : Appointed M01 Instruction Stop
0011 : M98 Format Error
0012 Motion Run Error
:
0013 : Current Program No Repair
0014 : G Program Format Error
0015 : M99 Instruction Abort
0016 : Motion Abort
0017 Illegal char
:
0018 : Noneffective Exegesis Character
0019 : Illegal G Code
0020 GCode RadialOffset Num Err
:
0021 : Noneffective GCode RadialOffset
0022 Arc Appointed Error
:
0023 : Appointed Noneffective Plane
0024 : M98 Instruction Abort
0025 Spindle Appointed Number Error
:
0026 : MCode Instruction Abort
0027 Spi Appointed Err
:
0028 : Motion Repeat Request
0029 : Appointed Arc Nonentity
0030 Missing X Code Error
:
0031 : Missing X Code Error
G code program running alarm info
System environment alarm info
