Note
078 X Servo Home Dir
079 Y Servo Home Dir
080 Z Servo Home Dir
081 4 Servo Home Dir
Range
Unit
Authority
Default
Effective time
Note
082 X Ext Home Eanble
083 Y Ext Home Eanble
084 Z Ext Home Eanble
085 4 Ext Home Eanble
Range
Unit
Authority
Default
Effective time
Note
: Set the maximum acceleration of every axis. This setting will affect the
track speed optimization of pretreatment to every axis. If a high value is
set, the axis response time will be shortened and characteristics of the
motor will be improved according to the machine tool.
This parameter also affects the home function and limit stop function.
Hard limit function: Use hard limit in software scanning mode, in which
the hard limit decelerates and stops according to the maximum
acceleration of this axis. Therefore, if this value is too high, the machine
tool will stop in emergency, and if this value is too low, it will cause too
much overshoot.
Home function: the home acceleration of every axis uses this value.
: 0~1
: None
: Super Admin
: 0
: Instant
: This parameter determines the Z phase search direction when servo Z
phase enable parameter is enabled in P2.009~P2.016.
0: Positive
1: Negative
: 0~1
: None
: Super Admin
: 1
: Instant
: When mechanical home mode is selected, this parameter determines
whether external deceleration switch should be searched. If this parameter
is set to 0, and P2.009~P2.016 (servo Z phase enable) is also set to 0, the
home mode sets current point as the home directly in mechanical mode.
0: No
1: Yes
11. System parameters
