Adtech CNC Technology Co., Ltd.
042 Y Round Setting
043 Z Round Setting
044 4 Round Setting
Range
Unit
Authority
Default
Effective time
Note
045
X physial Assign Num<●>
046
Y physial Assign Num<●>
047
Z physial Assign Num<●>
048
4 physial Assign Num<●>
Range
Unit
Authority
Default
Effective time
Note
049
spindle physial Assign Num<●>
Range
Unit
Authority
Default
Effective time
Note
050 X Encoder bit(p)
051 Y Encoder bit(p)
052 Z Encoder bit(p)
053 4 Encoder bit(p)
Range
- 64 -
: 0~9999999
: Pulse
: Super Admin
: 0
: Restart
: Round function is available on hardware version 1.5 or later only;
This function is used to prevent the logic counting of axis exceeding the
maximum counting range (2147483648) and causing overflow error;
Generally, overflow occurs only when the axis is set to rotary. The system
will calculate the corresponding pulse limit according to the gear ratio of
current axis and assign to the ROUND parameter of corresponding axis,
if current axis is set to rotary and uses 360° display mode after the system
getting P2.062~P2.069 parameters. The user can check the change of this
parameter when the rotary axis display function is enabled. The user can
modify the changed parameters, and the finally displayed number will be
effective.
This parameter requires restart to take effect; the corresponding axis must
be rotary and set to 360° display (P2.062~069);
: 0~4
: Pulse port sequence No.
: Super Admin
:
: Restart
: In default mode, the actual number of every axis corresponds to the silk
screen number on the shell. If certain function axis is abnormal, you can
replace the axis through this function. For example, set P2.045 to 4,
P2.048 to 1, then, any operation to X axis will be the operation to A axis
encoder port on the shell.
0: no such axis
1~4: corresponding to 1#-4# axis
: 0~4
: Pulse port sequence No.
: Super Admin
:
: Restart
: It is set to 0 by default, indicating that the principal axis is in variable
frequency control mode, i.e. analog or gear position control mode. To use
servo principal axis, a coding port is required (servo principal axis must
be in position control mode); you can modify this parameter to specify
the function.
0: variable frequency principal axis adjusted by analog
1~4: corresponding to 1#-4# axis
Note: If a pulse port is specified as the function port of principal axis, the
pulse port should be removed from previously corresponding function
axis number, or else the system will assign to principal axis after restarted
and the original function axis will be invalid.
: 0~9999
