Adtech ADT-CNC4620 Maintenance Manual page 79

Adtech CNC Technology Co., Ltd.
Note
063 Safe Signal
... ...
087 TCheck Limit DetectPort
Range
Unit
Authority
Default
Effective time
Note
083 IO Conf in RESET 00~15
084 IO Conf in RESET 16~23
Range
Unit
Authority
Default
Effective time
Note
: Output terminal No. configuration is same as input terminal
configuration. Output terminal No. and wire No. are mapped
: 0~23
: Terminal No.
: Super Admin
: The port table in the manual
: Instant
: System functions correspond to assigned terminal No.;
Terminal No. is also set by parameter 15~62, and mapped to specified
wire No.;
To shield this function, you can type 8888 and press Insert. This
operation is in background, and displays "255" if the operation is
successful.
: 0~65535
:
: Super Admin
: 65404
243
: Instant
: Used to configure the IO signal that the system needs to reset when there
is alarm.
Use binary system to configure in positions.
For example: 83:65404, is 1111 1111 0111 1100 in binary system;
Which indicates that port 0, 1 and 7 won't be reset due to system pause
or alarm.
11. System parameters
- 75 -
