Adtech CNC Technology Co., Ltd.
Process variables are to customize the names of 20 variables (#100~#999) according to CSV configuration table, so that
the variable names have visual meanings. In programs, the user customized variables are transferred with variable
number.

9.11 Current mode instruction info

Display the G code mode info of current system;
In [Monitor] interface, you can check the running code info of current system:
Motion instruction:
Select plane:
Coordinate logic:
Workpiece coordinate system:
Radius compensation:
Length compensation:
Compound instruction retracting plane: G98, G99
Principal axis rotation:
Tool No.:
- 40 -
G00, G01
G17, G18, G19
G90, G91
G54, G59, G591...G599
G40, G41, G42
G43, G44, G49
S
T
9. Program saving & editing
