Black - Directed XpressKit Installation Manual

Platform: DBALL2
Firmware TL6 :
Vehicle Wiring Reference Chart Type
Wire Information
Function Color
Toyota Corolla Smart key 2014-2016
HS CAN High Red
HS CAN Low White
12V Green 16
SLP Green
BTX Empty 25
BRX Empty 26
Parking Lights White
Autolight Violet
PTS

Black

-
Pin Polarity Location
6 Data Located at OBDII.
14 Data Located at OBDII.
(+) Located at OBDII.
4 (-) Steering Lock under steering column.
Data Middle connector Body ECU on dash fuse box.
Data Middle connector Body ECU on dash fuse box.
30 (-) Middle connector Body ECU on dash fuse box.
28 cut Middle connector Body ECU on dash fuse box.
1 (-) Push-to-Start Switch.
5
Connector Information
Rev.: 20 708 1 15
Page 15
Color Pins
White 16
White 16
White 16
Black 7
White 30
White 30
White 30
White 30
Black 10
