Lexus Gs 350 (Smart Key) - Directed XpressKit Installation Manual

Platform: DBALL2
Firmware TL6 :
Vehicle Wiring Reference Chart Type
Wire Information
Function Color
Lexus G350 (Smart Key) 2016
HS CAN 1 High Red
HS CAN 1 Low Gray or White
HS CAN 2 High Red
HS CAN 2 Low Gray
BTX Black
BRX Green or White 26
Autolight Red
12V Black or White 16
Parking Lights Black
PTS Green
SLP Blue
Trunk Release Yellow
- 8
Pin Polarity Location
14 Data Middle connector Body ECU on dash fuse box. White 30
13 Data Middle connector Body ECU on dash fuse box. White 30
9 Data Bottom 28 pin connector of ECU.
10 Data Bottom 28 pin connector of ECU.
25 Data Middle connector Body ECU on dash fuse box. White 30
Data Middle connector Body ECU on dash fuse box. White 30
28 Cut Middle connector Body ECU on dash fuse box. White 30
(+) Located at OBDII.
30 (-) Middle connector Body ECU on dash fuse box. White 30
1 (-) Push-to-Start Switch.
4 (-) Steering Lock under steering column.
8 (-) Bottom 28 pin connector of ECU.
Connector Information
© 201 Directed. 7
Rev.: 20 708 1 15
Page 22
Color Pins
White 28
White 28
Black 16
Black 10
Black 7
White 28
All rights reserved.
