White - Directed XpressKit Installation Manual

Platform: DBALL2
Firmware TL6 :
Wire Information
Function Color
Toyota RAV4 (Smart Key) 2013-2015
HS CAN High Black
HS CAN Low

White

BTX Blue
BRX Red
Autolight Green
12V Blue
Parking Lights White
PTS Dk. Green
SLP Green
Pin Polarity Location
6 Data Located at OBDII.
14 Data Located at OBDII.
25 Data Body ECU on dash fuse box.
26 Data Body ECU on dash fuse box.
28 Cut Body ECU on dash fuse box.
16 (+) Located at OBDII.
30 (-) Body ECU on dash fuse box.
1 (-) Push-to-Start Switch.
4 (-) Steering Lock under steering column.
Connector Information
© 201 Directed. 7
Rev.: 20 708 1 15
Page 13
Color Pins
Black 16
Black 16
White 30
White 30
White 30
Black 16
White 30
Black 10
Black 7
