Rev.: 20 708 - Directed XpressKit Installation Manual

Platform: DBALL2
Firmware TL6 :
Vehicle Wiring Reference Chart Type
Wire Information
Function Color
Toyota RAV4 Hybrid (Smart Key) 2016-2017
HS CAN High Green
HS CAN Low White
BTX Blue
BRX Red
Autolight Green
12V Blue
Parking Lights White
PTS Dk. Green 1
Start Enable Lt. Blue
SLP Lt. Green
- 7
Pin Polarity Location
14 Data Body ECU on bottom dash fuse box. White 30
13 Data Body ECU on bottom dash fuse box. White 30
25 Data Body ECU on bottom dash fuse box. White 30
26 Data Body ECU on bottom dash fuse box. White 30
28 Cut Body ECU on bottom dash fuse box. White 30
16 (+) Located at OBDII.
30 (-) Body ECU on bottom dash fuse box. White 30
(-) Push-to-Start Switch.
7 (+) Certification ECU behind glovebox.
4 (+) Steering Lock under column.
Connector Information
© 201 Directed.

Rev.: 20 708

1 15
Page 20
Color Pins
White 16
Black 10
White 18
Black 7
7 All rights reserved.
