Directed XpressKit Installation Manual page 18

Platform: DBALL2
Firmware TL6 :
Wire Information
Function Color
Toyota Corolla (Smart Key) 2017
SLP Green
PTS Black
12V Green
BTX Empty, insert pin 25
BRX Empty, insert pin 26
Parking Lights White
Autolight Violet
HS CAN High Black
HS CAN Low White
Toyota RAV4 (Smart Key) 2016-2017
12V Blue
SLP Lt. Green
HS CAN High Green
HS CAN Low White
BTX Blue
BRX Red
Parking Lights White
Autolight Green
PTS Dk. Green
Pin Polarity Location
4 (-) Steering lock under steering column.
1 (-) PTS (Push-to-Start) switch.
16 (+) OBDII.
Data Body ECU on bottom dash fuse box.
Data Body ECU on bottom dash fuse box.
30 (-) Body ECU on bottom dash fuse box.
28 cut Body ECU on bottom dash fuse box.
14 Data Body ECU on bottom dash fuse box.
13 Data Body ECU on bottom dash fuse box.
16 (+) Located at OBDII.
4 (-) Steering Lock under steering column. Black or Blue
14 Data Body ECU on bottom dash fuse box.
13 Data Body ECU on bottom dash fuse box.
25 Data Body ECU on bottom dash fuse box.
26 Data Body ECU on bottom dash fuse box.
30 (-) Body ECU on bottom dash fuse box.
28 cut Body ECU on bottom dash fuse box.
1 (-) Push-to-Start Switch.
Connector Information
Color
Black
Black
Black
White
White
White
White
White
White
Black
White
White
White
White
White
White
Black
© 201 Directed. 7
Rev.: 20 708 1 15
Page 18
Pins
7
10
16
30
30
30
30
30
30
16
7
30
30
30
30
30
30
10
