Directed XpressKit Installation Manual page 17

Platform: DBALL2
Firmware TL6 :
Vehicle Wiring Reference Chart Type 6
Wire Information
Function Color
Toyota Avalon (Smart Key) 2016
12V Red
SLP Green
HS CAN High Pink
HS CAN Low White
BTX Brown
BRX Lt. Green
Parking Lights Red
Autolight Tan
PTS Violet
Toyota Avalon Hybrid 2016
12V Red
SLP Green
HS CAN High Pink
HS CAN Low White
BTX Brown
BRX Lt. Green
Parking Lights Red
Autolight Tan
PTS Violet
Toyota Camry (Smart Key) 2016-2017
SLP Green or Pink 4
PTS Violet
12V Red
BTX Green
BRX Red
Parking Lights Black
Autolight Green
HS CAN High Pink
HS CAN Low White
Toyota Camry Hybrid (Smart Key) 2016-2017
SLP Green or Pink 4
PTS Violet
12V Red
BTX Green
BRX Red
Parking Lights Black
Autolight Green
HS CAN High Pink
HS CAN Low White
-
Pin Polarity Location
16 (+) Located at OBDII.
4 (-) Steering Lock under steering column. Black or Blue
14 Data Body ECU on bottom dash fuse box.
13 Data Body ECU on bottom dash fuse box.
25 Data Body ECU on bottom dash fuse box.
26 Data Body ECU on bottom dash fuse box.
30 (-) Body ECU on bottom dash fuse box.
28 cut Body ECU on bottom dash fuse box.
1 (-) Push-to-Start Switch.
16 (+) Located at OBDII.
4 (-) Steering Lock under steering column. Black or Blue
14 Data Body ECU on bottom dash fuse box.
13 Data Body ECU on bottom dash fuse box.
25 Data Body ECU on bottom dash fuse box.
26 Data Body ECU on bottom dash fuse box.
30 (-) Body ECU on bottom dash fuse box.
28 cut Body ECU on bottom dash fuse box.
1 (-) Push-to-Start Switch.
(-) Steering lock under steering column.
1 (-) PTS (Push-to-Start) switch.
16 (+) OBDII.
25 Data Body ECU on bottom dash fuse box.
26 Data Body ECU on bottom dash fuse box.
30 (-) Body ECU on bottom dash fuse box.
28 cut Body ECU on bottom dash fuse box.
14 Data Body ECU on bottom dash fuse box.
13 Data Body ECU on bottom dash fuse box.
(-) Steering lock under steering column.
1 (-) PTS (Push-to-Start) switch.
16 (+) OBDII.
25 Data Body ECU on bottom dash fuse box.
26 Data Body ECU on bottom dash fuse box.
30 (-) Body ECU on bottom dash fuse box.
28 cut Body ECU on bottom dash fuse box.
14 Data Body ECU on bottom dash fuse box.
13 Data Body ECU on bottom dash fuse box.
Connector Information
Color
Black
White
White
White
White
White
White
Black
Black
White
White
White
White
White
White
Black
Black or Blue
Black
Black
White
White
White
White
White
White
Black or Blue
Black
Black
White
White
White
White
White
White
© 201 Directed.
Rev.: 20 708 1 15
Page 17
Pins
16
7
30
30
30
30
30
30
10
16
7
30
30
30
30
30
30
10
7
10
16
30
30
30
30
30
30
7
10
16
30
30
30
30
30
30
7 All rights reserved.
