Automationdirect.com DL05 User Manual page 258

Chapter 5: Standard RLL Instructions
Data Label (DLBL)
1 1
The Data Label instruction marks the beginning of
DS5 Used
an ASCII/numeric data area. DLBLs are programmed
HPP Used
2 2
after the End statement. A maximum of 64 DLBL
instructions can be used in a program. Multiple
NCONs and ACONs can be used in a DLBL area.
3 3
4 4
⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠A
Constant ⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠K
5 5
ASCII Constant (ACON)
6 6
The ASCII Constant instruction is used with the
DS5 Used
DLBL instruction to store ASCII text for use with
HPP Used
7 7
other instructions. Two ASCII characters can be stored
in an ACON instruction. If only one character is stored
in an ACON a leading space will be inserted.
8 8
9 9
Constant ⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠A
10 10
Numerical Constant (NCON)
11 11
The Numerical Constant instruction is used with the
DS5 Used
DLBL instruction to store the HEX ASCII equivalent
HPP Used
12 12
of numerical data for use with other instructions. Two
digits can be stored in an NCON instruction.
13 13
14 14
Constant ⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠K
a A
b B
c C
D D
5-112 DL05 Micro PLC User Manual, 6th Edition, Rev. D
Operand Data Type
Operand Data Type
Operand Data Type
K aaa
DLBL
DL05 Range
aaa
1-FFFF
ACON
A aaa
DL05 Range
aaa
0-9 A-Z
NCON
K aaa
DL05 Range
aaa
0-FFFF
