Load Address (LDA)
1 1
The Load Address instruction is a 16 bit instruction. It converts
DS5 Used
any octal value or address to the HEX equivalent value and
HPP Used
2 2
loads the HEX value into the accumulator. This instruction is
useful when an address parameter is required since all addresses
for the DL05 system are in octal.
3 3
4 4
Octal Address ⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠⸠O
5 5
Discrete Bit Flags
6 6
NOTE: Two consecutive Load instructions will place the value of the first load instruction onto the
7 7
accumulator stack.
8 8
In the following example when X1 is on, the octal number 40400 will be converted to a HEX
4100 and loaded into the accumulator using the Load Address instruction. The value in the
lower 16 bits of the accumulator is copied to V2000 using the Out instruction.
9 9
DirectSOFT 5
10 10 Direct SOFT32
X1
11 11
12 12
13 13
14 14
A a
Handheld Programmer Keystrokes
B b
$
STR
C c
SHFT
E
4
D D
GX
OUT
