5.2.4.3. Web Configuration

Parameter
MAC Address
VLAN ID
Apply
Refresh
MAC Address
VLAN ID
Action
Total Counts

5.3. Port Mirror

5.3.1. Introduction

Port-based Mirroring
The Port-Based Mirroring is used on a network switch to send a copy of network packets
sent/received on one or a range of switch ports to a network monitoring connection on another
switch port (Monitor to Port). This is commonly used for network appliances that require
monitoring of network traffic, such as an intrusion-detection system.
Description
Enter the MAC address of a computer or device that you want to
refusal.
Valid format is hh:hh:hh:hh:hh:hh.
Enter the VLAN ID to apply to the computer or device.
Click Apply to take effect the settings.
Click Refresh to begin configuring this screen afresh.
This field displays a MAC address.
This field displays the VLAN ID of the MAC address entry.
Click Delete to remove this manually entered MAC address entry from
the refusal MAC address table.
This field displays the total entries in the refusal MAC table.
