Vivotek AW-IHT-1270 User Manual page 11

IEEE 802.3ad
IEEE 802.3af
IEEE 802.3at
Performance
Switching fabric
L2 forwarding
MAC Entries
Jumbo frame
Physical Ports
8 x 10/100/1000Base-T (PSE)
4 Gigabit SFP slots
1 x Console port (RJ-45 to RS-232)
Mechanical & Environmental
Dimension (WxHxD)
Weight
Mounting
Housing
Wide Operating temperature
Storage temperature
Operating humidity
Storage humidity
PoE
Power Available at PD
Max Power delivered by PSE
Voltage Range (at PSE)
Voltage Range (at PD)
Maximum Current
Maximum Cable resistance
Per port up to 30 W and up to limited power budget
Output capacity for PoE: 240 W
PoE supported mode: Mode A
Notice: PoE Power at PDs (Powered Devices) for 100 meters deployment distance
DC Power Input
RJ-45 Distance (Cat5e or above)
PoE Power at PDs
Port Trunk with LACP
Power over Ethernet (PoE)
High Power over Ethernet (PoE+)
24Gbps
17.86Mpps
16 K
10 K
50x161.5x122.2mm (1.97x6.36x4.81 inch)
860g
DIN-Rail
IP30 protection
-40 to 70℃
-40 to 85℃
10% to 95% RH (Non Condensing)
5% to 95% RH (Non Condensing)
25.50 W
30 W
50-57V
42.5-57V
600 mA
12.5 Ω (Category 5)
48~52V DC
100m
802.3af
3
54~57V DC
100m
802.3at
