6.9.3.

Web Configuration

Parameter
State
MAC Address
Port
State
Loop Recovery
Recovery Time
Apply
Refresh
Loop Guard Status
Port
Description
Select this option to enable loop guard on the Switch.
Enter the destination MAC address the probe packets will be sent to.
If the port receives these same packets the port will be shut down.
Select a port on which to configure loop guard protection.
Select Enable to use the loop guard feature on the Switch.
Select Enable to reactivate the port automatically after the designated
recovery time has passed.
Specify the recovery time in minutes that the Switch will wait before
reactivating the port. This can be between 1 to 60 minutes.
Click Apply to save your changes to the Switch.
Click Refresh to begin configuring this screen afresh.
This field displays a port number.
