Vivotek AW-IHT-1270 User Manual page 161

Max Hops
Instance
Priority
Port Parameters:
Parameter
network. The allowed range is 6 to 40 seconds.
Selects an instance which you want to configure.
Configures the priority for the instance.
Priority is used in determining the root switch, root port and designated
port. The switch with the highest priority (lowest numeric value)
becomes the STP root switch. If all switches have the same priority,
the switch with the lowest MAC address will then become the root
switch.
Enter a value from 0~61440.
The lower the numeric value you assign, the higher the priority for this
bridge.
Priority determines the root bridge, which in turn determines the Root
Hello Time, Root Maximum Age and Root Forwarding Delay.
Description
153
