Port Information
0x0100 to 1 word
0x0109
0x0200 to 20 words
0x0213 (port 1)
0x0220 to
0x0233 (port 2)
...
0x0320 to
0x0333 (port
10)
0x0400 to 2 words
0x0413 (port 1
to 10)
0x0440 to 2 words
0x0453 (port 1
to 10)
0x0480 to 2 words
0x0493 (port 1
to 10)
0x04C0 to 2 words
0x04D3 (port 1
to 10)
STP Information
0x0500 1 word
Xpress Ring Information
0x0501 1 word
0x0510 1 word
HEX Port 1 to 10 Link Status
0x0000: Link down
0x0001: 10M-Full-FC_ON (FC: Flow Control)
0x0002: 10M-Full-FC_OFF
0x0003: 10M-Half-FC_ON
0x0004: 10M-Half-FC_OFF
0x0005: 100M-Full-FC_ON
0x0006: 100M-Full-FC_OFF
0x0007: 100M-Half-FC_ON
0x0008: 100M-Half-FC_OFF
0x0009: 1000M-Full-FC_ON
0x000A: 1000M-Full-FC_OFF
0x000B: 1000M-Half-FC_ON
0x000C: 1000M-Half-FC_OFF
0xFFFF: No port
ASCII Port 1 to 10 Description
Port Description = "100TX,RJ45." Or "1000TX,SFP."
Word 0 Hi byte = '1'
Word 0 Lo byte = '0'
Word 1 Hi byte = '0'
Word 1 Lo byte = 'T'
...
Word 4 Hi byte = '4'
Word 4 Lo byte = '5'
Word 5 Hi byte = '.'
Word 5 Lo byte = '\0'
HEX Port 1 to 10 Tx Packets
Ex: port 1 Tx Packet Amount = 0x87654321
Word 0 =8765
Word 1 = 4321
HEX Port 1 to 10 Rx Packets
Ex: port 1 Rx Packet Amount = 0x123456
Word 0 = 0012
Word 1 = 3456
HEX Port 1 to 10 Tx Error Packets
Ex: port 1 Tx Error Packet Amount = 0x87654321
Word 0 =8765
Word 1 = 4321
HEX Port 1 to 10 Rx Error Packets
Ex: port 1 Rx Error Packet Amount = 0x123456
Word 0 = 0012
Word 1 = 3456
HEX STP Status:
0x0000 : STP is disabled.
0x0001 : STP
0x0002 : RSTP
0x0003 : MSTP
HEX Xpress Ring Status on the Switch:
0x0000 :
0x0001 :
HEX Status of Xpress-ring1 of the Switch
0x0000 :
0x0001 :
120
.
Disabled
Enabled
Disabled
Enabled
