Set your Printing Preferences

Set the Printable Area

This functionality allows you to adjust the printable area settings for
standard CD/DVD 120 mm media. These settings control the outer and inner
diameters so that the label prints on the disc without overlapping the disc
edges.
Tip: Printable Area settings created within a CD Designer label file will
override the printer and fax settings in Windows.
1. Access Printing Preferences.
Refer to page 12 for instructions.
2. Select the Advanced tab.
3. View or change the Printable Area preferences.
a. Select the Modify button at the bottom of the Advanced tab. The
Printable Area Settings window opens.
b. To modify only Standard Area settings, select the Standard radio
button.
i. Enter the desired Outer Diameter.
ii. Enter the desired Inner Diameter.
c. To print on a disc with a stacking ring, select the Advanced radio
button. The Hub Area settings display.
i. Enter the desired Outer Diameter for the hub.
ii. Enter the desired Inner Diameter for the hub.
d. Select OK to save the changes. The Printable Area Settings window
closes.
e. If necessary, select Default to return to the default
f. When you have made the desired choices in the Rimage Everest
Encore Printing Preferences window, select Apply.
4. Select OK to close the Rimage Everest Encore Printing Preferences
window.
2004001_A

Adjust the Print Alignment and Color Density

1. Access
2. Select the Utility tab.
3. Select Status Monitor... button. The Rimage Everest Encore Status
Monitor window opens with the Status tab active.
Tip: On the Status tab, you can view the progress of a print job, the type
of print ribbon installed, and the estimated percentages of unused
ribbon for the print and retransfer ribbons. To reset the estimate for the
number of prints remaining on the ribbons, refer to the
Status
4. Select the Printer Information tab to view or change the Print Alignment
and Color Density settings.
Tips:
•
•
a. View or change the Print Alignment Settings.
For more information visit www.rimage.com/support
Printing Preferences. Refer to page 12 for instructions.
section on page 15.
The Printer Information tab also displays the current firmware
version and serial number of your Everest Encore printer.
Select Default to return to the default Print Alignment Settings or
Color Density Settings.
Select the Modify button from the Print Alignment Settings
i.
pane. The Print Alignment Settings window opens.
ii. Select the desired Color/Monochrome setting in the Horizontal
Alignment Settings pane to modify the horizontal alignment for
all ribbon types.
iii. Select the desired Color setting to modify the vertical alignment
for prints with a CMY ribbon.
iv. Select the desired Monochrome setting to modify the vertical
alignment for prints with a monochrome ribbon.
v. Select OK to save the changes. The Print Alignment Settings
window closes.
View the Ribbon
