Clean the Sensors On an
Everest III, Everest 600 or
Integrated Everest 400 Printer

Advertisement

loading
Need help?

Need help?

Do you have a question about the Everest 600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rimage Everest 600

Summary of Contents for Rimage Everest 600

  • Page 1 Clean the Sensors On an Everest III, Everest 600 or Integrated Everest 400 Printer...
  • Page 2 Use this procedure to clean a sensor on an Everest™ III, 600 or integrated 400 printer. Rimage approved parts must be used for this process. The product warranty may become void if parts not approved by Rimage are used; equipment or parts are tampered with, misused, neglected, or modified in any respect without the written consent of Rimage.
  • Page 3 4. Remove the retransfer ribbon carrier. a. Open latches 2 and 3. b. Pull out the retransfer ribbon carrier. Note: The retransfer ribbon carrier cannot be removed from the printer. Retransfer Ribbon Carrier Latch 2 Latch 3 2001465_C Rimage Corporation ©2010 Page 2...
  • Page 4 Clean the Sensors on an Everest Printer 5. Locate the sensors. • Print ribbon sensor • Upper sensor • Lower sensor Upper Sensor Print Ribbon Sensor Lower Sensor 2001465_C Rimage Corporation ©2010 Page 3...
  • Page 5 Important! Do not clean the printer sensors until the 5400N or 3400 system is completely powered off. a. Disconnect the power cord from the back of the 5400N or 3400. b. Disconnect the power cord from the power outlet. Power Cord 2001465_C Rimage Corporation ©2010 Page 4...
  • Page 6 Clean the Sensors on an Everest Printer 5. Locate the sensors. • Print ribbon sensor • Upper sensor Upper Sensor • Lower sensor Print Ribbon Sensor Lower Sensor 2001465_C Rimage Corporation ©2010 Page 5...

  • Page 7: Clean The Sensors

    4. Position the can of compressed air’s nozzle in the unnotched end of the handle. 5. Blow compressed air in to the end of the handle for one to two seconds 6. Repeat two to three times. 2001465_C Rimage Corporation ©2010 Page 6...

  • Page 8: Prepare The Printer For Use

    1. Replace the print ribbon carrier. 2. Replace the retransfer ribbon carrier. 3. Close the latches. • Everest III and Everest 600: Close latches 1, 2 and 3. • Everest 400: Turn the center latch clockwise to lock it. 4. Close the printer cover.
