FloBoss S600 Instruction Manual

1.3 Config 600 Software

Config 600 Configuration Software is a suite of editors that provide the capability to monitor, configure,
and calibrate FloBoss S600 Flow Managers. Config 600 Pro software provides a full workbench for
configuration building. Config 600 Lite software allows sending, receiving and editing of existing
configurations. Config 600 Lite is suggested for users whose configurations have been initially created by
their local sales channel, integrator, or the factory. IPL600 software allows only configuration transfer and
communication port configuration.
1.3.1 IPL 600
The IPL 600 software is the "Interactive Program Loader" (available separately). The IPL 600 software
sends VxWorks firmware and receives and sends configurations. In Config Lite and Config Pro, this
interface is referred to as the Transfer Editor.
NOTE: The FloBoss S600 will not operate until a configuration has been sent from the host PC.
1.3.2 Config 600 Lite
The Config 600 Lite editors can be used to modify pre-developed configurations, transfer configurations,
edit items on the front panel display, and edit report formats.
NOTE: Config 600 Lite is used to custom configure a new FloBoss S600 during installation.
Config 600 Lite allows you to perform the following functions:
♦ Edit initialization process data, including orifice size, analog input scaling, alarm limits, and keypad
values.
♦ Build and customize Modbus slave maps, Modbus master polling sequences, front panel displays,
and period report formats.
♦ Customize the alarm system, including alarm groups, suppression, and inhibits.
♦ Configure system security by setting user names and passwords, and assigning access levels for
each data object on the displays.
♦ Specify the engineering units and totalization rollover value.
♦ Reflash the CPU module firmware with software upgrades and transfer configurations via the
Transfer Editor.
1.3.3 Config 600 Pro
The Config 600 Pro editors allow you to configure the FloBoss S600 from a PC.
NOTE: The Config 600 Pro is used to create and develop new FloBoss S600 applications.
Config 600 Pro allows you to perform the following functions:
♦ Create a new application from base templates for gas, liquid, and prover applications.
Rev Sep/04 Information 1-5
