Item
Description
1
Rear LFF drive cage power cable
2
Rear LFF drive cage Mini-SAS Y-cable
•
Four-bay LFF hot-plug SAS/SATA rear drive cabling to the P440 Smart Array Controller installed in the
PCIe expansion slot 5, 6 or 7
Item
Description
1
Rear LFF drive cage Mini-SAS Y-cable
2
Rear LFF drive cage power cable
Two-bay SFF hot-plug SAS/SATA rear drive cabling
•
Two-bay SFF hot-plug SAS/SATA rear drive cabling to the front drive cage 2 backplane
Two-bay SFF hot-plug SAS/SATA rear drive cabling
151
