2.4.1

Electrical Characteristics

Power supply pins on the module's connectors limit the amount of input power. The following table provides an overview of the limitations for
pinout Type 6 (dual connector, 440 pins).
Power Rail Module Pin
Current Capability
(Amps)
VCC_12V 12
VCC_5V-SBY 2
VCC_RTC 0.5
2.4.2

Rise Time

The input voltages shall rise from 10% of nominal to 90% of nominal at a minimum slope of 250V/s. The smooth turn-on requires that during
the 10% to 90% portion of the rise time, the slope of the turn-on waveform must be positive.
2.5

Power Consumption

The power consumption values were measured with the following setup:
• conga-TCA5 COM
• modified congatec carrier board
• conga-TCA5 cooling solution
• Microsoft Windows 10 (64 bit)
Note
The CPU was stressed to its maximum workload with the Intel
Copyright © 2017 congatec AG
Nominal Input Derated
Input (Volts) Range Input (Volts)
(Volts)
12 11.4-12.6 11.4
5 4.75-5.25 4.75
3 2.0-3.3
Thermal Analysis Tool
®
Max. Input Ripple Max. Module Input
(10Hz to 20MHz) Power (w. derated input)
(mV) (Watts)
+/- 100 137
+/- 50 9
+/- 20
TA50m10
Assumed Max. Load
Conversion Power
Efficiency (Watts)
85% 116
