5.1.6

VGA

The Intel Apollo Lake SoC does not natively support VGA interface. However, the conga-TCA5 can support this interface by integrating an

optional DisplayPort to VGA adapter chip.

Note

For VGA support, you need a customized conga-TCA5 variant.

5.1.7

The conga-TCA5 provides an interface that supports HDA audio codecs.

5.1.8

The conga-TCA5 offers two non-legacy UART interfaces. These interfaces support up to 3.68 Mbps (high-speed mode). They do not support

hardware handshake and flow control.

Note

1. The UART interfaces require Intel UART driver to function.

2. The UART signals can optionally be driven via the LPC bus (assembly option)

5.1.9

The conga-TCA5 supports the implementation of ExpressCards, which requires the dedication of one USB port and a x1 PCI Express link for

each ExpressCard used.

5.1.10

The conga-TCA5 offers a 4-bit SD interface for SD/MMC cards on the A-B connector. The SD signals are multiplexed with GPIO signals and

controlled by the congatec Board controller. The SD card controller in the Storage Control Cluster of the SoC supports the SD interface with

up to 832 Mbps data rate using 4 parallel data lines.

TA50m10

27/72
