Table 15
General Purpose I/O Signal Descriptions
Signal
Pin # Description
GPO0
A93
General purpose output pins.
Shared with SD_CLK. Output from COM Express, input to SD
GPO1
B54
General purpose output pins.
Shared with SD_CMD. Output from COM Express, input to SD
GPO2
B57
General purpose output pins.
Shared with SD_WP. Output from COM Express, input to SD
GPO3
B63
General purpose output pins.
Shared with SD_CD. Output from COM Express, input to SD
GPI0
A54
General purpose input pins. Pulled high internally on the module.
Shared with SD_DATA0. Bidirectional signal
GPI1
A63
General purpose input pins. Pulled high internally on the module.
Shared with SD_DATA1. Bidirectional signal
GPI2
A67
General purpose input pins. Pulled high internally on the module.
Shared with SD_DATA2. Bidirectional signal
GPI3
A85
General purpose input pins. Pulled high internally on the module.
Shared with SD_DATA3. Bidirectional signal.
Table 16
Power and System Management Signal Descriptions
Signal
Pin # Description
PWRBTN#
B12
Power button to bring system out of S5 (soft off), active on falling edge.
SYS_RESET#
B49
Reset button input. Active low input. Edge triggered.
System will not be held in hardware reset while this input is kept low.
CB_RESET#
B50
Reset output from module to Carrier Board. Active low. Issued by module chipset and
may result from a low SYS_RESET# input, a low PWR_OK input, a VCC_12V power
input that falls below the minimum specification, a watchdog timeout, or may be
initiated by the module software.
PWR_OK
B24
Power OK from main power supply. A high value indicates that the power is good.
SUS_STAT#
B18
Indicates imminent suspend operation; used to notify LPC devices.
SUS_S3#
A15
Indicates system is in Suspend to RAM state. Active-low output. An inverted copy of
SUS_S3# on the carrier board (also known as "PS_ON#") may be used to enable the
non-standby power on a typical ATX power supply.
SUS_S4#
A18
Indicates system is in Suspend to Disk state. Active low output.
Copyright © 2017 congatec AG
I/O
O 3.3V
O 3.3V
O 3.3V
O 3.3V
I 3.3V
I 3.3V
I 3.3V
I 3.3V
I/O
I 3.3VSB
I 3.3VSB
O 3.3V
I 3.3V
O 3.3VSB
O 3.3VSB
O 3.3VSB
TA50m10
PU/PD Comment
PU 10K
Pull-up only active in GPIO mode
3.3V
PU 10K
Pull-up only active in GPIO mode
3.3V
PU 10K
Pull-up only active in GPIO mode
3.3V
PU 10K
Pull-up only active in GPIO mode
3.3V
PU/PD Comment
PU 10k
3.3VSB
PU 10k
3.3 VSB
PU 100k
Connected via series diode to
3.3VSB
onboard voltage monitor
50/72
