Congatec COM Express conga-TCA5 User Manual page 12

Table 3 Industrial Variants
Part-No. 048510
Processor Intel ® Atom™ x7-E3950
Quad Core, 1.6GHz
L2 Cache 2 MB
Burst Frequency 2.0 GHz
Graphics Intel ® HD Graphics 505
GFX Base/Burst 500 MHz / 650 Mhz
Memory (DDR3L) 1866 M/T Dual Channel
LVDS Single/Dual 18/24 bpp
Optional VGA Yes
Default PCIe Lanes 3x PCIe lanes
DDI DP 1.2 / HDMI 1.4b / DVI
eMMC (SLC/MLC) Up to 32 GB MLC (optional)
Yes
SD Card
Max. TDP 12 W
Copyright © 2017 congatec AG
048511 048512
Intel ® Atom™ x5-E3940 Intel ® Atom™ x5-E3930
Quad Core, 1.6GHz Dual Core, 1.3GHz
2MB 2MB
1.8 GHz 1.8 GHz
Intel ® HD Graphics 500 Intel ® HD Graphics 500
400 MHz / 600 MHz 400 MHz / 550 MHz
1866 M/T Dual Channel 1866 M/T Dual Channel
Single/Dual 18/24 bpp Single/Dual 18/24 bpp
Yes Yes
3x PCIe lanes 3x PCIe lanes
DP 1.2 / HDMI 1.4b / DVI DP 1.2 / HDMI 1.4b / DVI
Up to 32 GB MLC (optional) Up to 32 GB MLC (optional) Up to 32 GB MLC (optional)
Yes Yes
9 W 6.5 W
TA50m10
048513 (with PCIe Switch)
Intel ® Atom™ x7-E3950
Quad Core, 1.6GHz
2 MB
2.0 GHz
Intel ® HD Graphics 505
500 MHz / 650 Mhz
1600MT/s dual channel
Single/Dual 18/24 bpp
Yes
5x PCIe lanes
DP 1.2 / HDMI 1.4b / DVI
Yes
12 W
12/72
