Congatec COM Express conga-TCA5 User Manual page 65

Pin Row C
C31 GND (FIXED)
C32 DDI2_CTRLCLK_AUX+
C33 DDI2_CTRLDATA_AUX-
C34 DDI2_DDC_AUX_SEL
C35 RSVD
C36 DDI3_CTRLCLK_AUX+ * 1
C37 DDI3_CTRLDATA_AUX- *
1
C38 DDI3_DDC_AUX_SEL * 1
C39 DDI3_PAIR0+ *
1
C40 DDI3_PAIR0- * 1
C41 GND (FIXED)
C42 DDI3_PAIR1+ *
1
C43 DDI3_PAIR1- * 1
C44 DDI3_HPD *
1
C45 RSVD
C46 DDI3_PAIR2+ * 1
C47 DDI3_PAIR2- *
1
C48 RSVD
C49 DDI3_PAIR3+ *
1
C50 DDI3_PAIR3- * 1
C51 GND (FIXED)
C52 PEG_RX0+ *
1
C53 PEG_RX0- * 1
C54 TYPE0# *
1
C55 PEG_RX1+ * 1
Note
Not supported on the conga-TCA5.
*1
Copyright © 2017 congatec AG
Pin Row D Pin
D31 GND (FIXED) C86
D32 DDI1_PAIR2+ C87
D33 DDI1_PAIR2- C88
D34 DDI1_DDC_AUX_SEL C89
D35 RSVD C90
D36 DDI1_PAIR3+ C91
D37 DDI1_PAIR3- C92
D38 RSVD C93
D39 DDI2_PAIR0+ C94
D40 DDI2_PAIR0- C95
D41 GND (FIXED) C96
D42 DDI2_PAIR1+ C97
D43 DDI2_PAIR1- C98
D44 DDI2_HPD C99
D45 RSVD C100
D46 DDI2_PAIR2+ C101
D47 DDI2_PAIR2- C102
D48 RSVD C103
D49 DDI2_PAIR3+ C104
D50 DDI2_PAIR3- C105
D51 GND (FIXED) C106
D52 PEG_TX0+ * C107
1
D53 PEG_TX0- * 1 C108
D54 PEG_LANE_RV# * C109
1
D55 PEG_TX1+ * 1 C110
Row C Pin Row D
PEG_RX10- * 1 D86 PEG_TX10- *
GND D87 GND
PEG_RX11+ * 1 D88 PEG_TX11+ *
PEG_RX11- * D89 PEG_TX11- *
1
GND (FIXED) D90 GND (FIXED)
PEG_RX12+ * 1 D91 PEG_TX12+ *
PEG_RX12- * D92 PEG_TX12- *
1
GND D93 GND
PEG_RX13+ * D94 PEG_TX13+ *
1
PEG_RX13- * 1 D95 PEG_TX13- *
GND D96 GND
RVSD D97 RSVD
PEG_RX14+ * 1 D98 PEG_TX14+ *
PEG_RX14- * D99 PEG_TX14- *
1
GND (FIXED) D100 GND (FIXED)
PEG_RX15+ * 1 D101 PEG_TX15+ *
PEG_RX15- * D102 PEG_TX15- *
1
GND D103 GND
VCC_12V D104 VCC_12V
VCC_12V D105 VCC_12V
VCC_12V D106 VCC_12V
VCC_12V D107 VCC_12V
VCC_12V D108 VCC_12V
VCC_12V D109 VCC_12V
GND (FIXED) D110 GND (FIXED)
TA50m10
1
1
1
1
1
1
1
1
1
1
1
65/72
