Carrier board designers can use as little or as many of the I/O interfaces as deemed necessary. The carrier board can therefore provide all
the interface connectors required to attach the system to the application specific peripherals. This versatility allows the designer to create a
dense and optimized package, which results in a more reliable product while simplifying system integration. Most importantly, COM Express™
modules are scalable, which means once an application has been created there is the ability to diversify the product range through the use
of different performance class or form factor size modules. Simply unplug one module and replace it with another; no redesign is necessary.
1.2

Options Information

The conga-TCA5 is available in six variants (two commercial and four industrial). The table below shows the different configurations available.
Check for the Part No. that applies to your product. This will tell you what options described in this user's guide are available on your particular
module.
Table 2 Commercial Variants
Part-No. 048530
Processor Intel
Dual Core 1.1 GHz
L2 Cache 2 MB
Burst Frequency 2.3 GHz
Graphics Intel
GFX Base/Burst 200 MHz / 650 MHz
Memory (DDR3L) 1866 M/T Dual Channel
LVDS Single/Dual 18/24 bpp
Yes
Optional VGA
Default PCIe Lanes 3x PCIe lanes
DDI DP 1.2 / HDMI 1.4b / DVI
eMMC (SLC/MLC) Up to 32 GB MLC (optional) Up to 32 GB MLC (optional)
SD Card Yes
Max. TDP 6 W
Copyright © 2017 congatec AG
048531
® Celeron ® N3350 Intel ® Pentium
Quad Core, 1.1 GHz
2 MB
2.5 GHz
® HD Graphics 500 Intel ® HD Graphics 505
200 MHz / 750 MHz
1866 M/T Dual Channel
Single/Dual 18/24 bpp
Yes
3x PCIe lanes
DP 1.2 / HDMI 1.4b / DVI
Yes
6 W
® N4200
TA50m10 11/72
