8.1

A-B Connector Signal Descriptions

Table 4 Intel High Definition Audio Link Signals Descriptions
®
Signal Pin #
AC/HDA_RST# A30
AC/HDA_SYNC A29
AC/HDA_BITCLK A32
AC/HDA_SDOUT A33
AC/HDA_SDIN0 B29-B30 Intel
Table 5 Gigabit Ethernet Signal Descriptions
Gigabit Ethernet Pin #
GBE0_MDI0+
GBE0_MDI0-
GBE0_MDI1+
GBE0_MDI1-
GBE0_MDI2+
GBE0_MDI2-
GBE0_MDI3+
GBE0_MDI3-
GBE0_ACT#
GBE0_LINK#
GBE0_LINK100#
GBE0_LINK1000#
Copyright © 2017 congatec AG
Description
Intel High Definition Audio Reset: This signal is the master hardware reset to
®
external codec(s).
Intel High Definition Audio Sync: This signal is a 48 kHz fixed rate sample
®
sync to the codec(s). It is also used to encode the stream number.
Intel High Definition Audio Bit Clock Output: This signal is a 24.000MHz
®
serial data clock generated by the Intel
Intel High Definition Audio Serial Data Out: This signal is the serial TDM
®
data output to the codec(s). This serial output is double-pumped for a bit rate
of 48 Mbps for Intel ® High Definition Audio.
High Definition Audio Serial Data In 0: This signal is the serial TDM
®
data input from the codec(s). This serial input is single-pumped for a bit rate of
24 Mbps for Intel ® High Definition Audio.
Description
A13 Gigabit Ethernet Controller 0: Media Dependent Interface Differential Pairs 0,
A12 1, 2, 3. The MDI can operate in 1000, 100, and 10Mbit/sec modes. Some pairs
A10 are unused in some modes according to the following:
A9
1000
A7
MDI[0]+/- B1_DA+/-
A6
A3
MDI[1]+/- B1_DB+/-
A2
MDI[2]+/- B1_DC+/-
MDI[3]+/- B1_DD+/-
B2 Gigabit Ethernet Controller 0 activity indicator, active low.
A8 Gigabit Ethernet Controller 0 link indicator, active low.
A4 Gigabit Ethernet Controller 0 100Mbit/sec link indicator, active low.
A5 Gigabit Ethernet Controller 0 1000Mbit/sec link indicator, active low.
High Definition Audio controller.
®
100 10
TX+/- TX+/-
RX+/- RX+/-
TA50m10
I/O PU/PD Comment
O 3.3V AC'97 codecs are not supported.
O 3.3V AC'97 codecs are not supported.
O 3.3V AC'97 codecs are not supported.
O 3.3V AC'97 codecs are not supported.
I 3.3V 2k2 PD AC'97 codecs are not supported.
AC/HDA_SDIN[2:1] signals are not
supported.
I/O PU/PD Comment
I/O Analog Twisted pair signals for
external transformer.
O 3.3VSB
O 3.3VSB
O 3.3VSB
O 3.3VSB
43/72
