Congatec COM Express conga-TCA5 User Manual page 17

Table 4 Measurement Description
The power consumption values were recorded during the following system states:
System State Description
S0: Minimum value
Lowest frequency mode (LFM) with minimum core voltage during
desktop idle.
S0: Maximum value Highest frequency mode (HFM/Turbo Boost).
S0: Peak value Highest current spike during the measurement of "S0: Maximum
value". This state shows the peak value during runtime
S3 COM is powered by VCC_5V_SBY.
S5 COM is powered by VCC_5V_SBY.
Note
1. The fan and SATA drives were powered externally.
2. All other peripherals except the LCD monitor were disconnected before measurement.
Table 5 Power Consumption Values
The tables below provide additional information about the power consumption data for each of the conga-TCA5 variants offered. The values
are recorded at various operating modes.
Part Memory H.W BIOS
No. Size Rev. Rev.
048510 2 x 4 GB A.1 R117
048511 2 x 4 GB TBD TBD
048512 2 x 4 GB A.0 R117
048513 2 x 4 GB TBD TBD
048530 2 x 4 GB A.0 R117
048531 2 x 4 GB A.0 R117
Note
With fast input voltage rise time, the inrush current may exceed the measured peak current.
Copyright © 2017 congatec AG
OS CPU
(64 bit) Variant
Windows 10 Intel Atom™ x7-E3950
®
Windows 10 Intel ® Atom™ x5-E3940
Windows 10 Intel Atom™ x5-E3930
®
Windows 10 Intel Atom™ x7-E3950
®
(with PCIe Switch)
Windows 10 Intel ® Celeron™ N3350
Windows 10 Intel Pentium N4200
® ®
Comment
The CPU was stressed to its maximum frequency.
The CPU was stressed to its maximum frequency.
Consider this value when designing the system's power supply to
ensure that sufficient power is supplied during worst case scenarios.
Current (Amp.)
Cores Freq/Turbo S0: S0:
(GHz) Min Max
4 1.6 / 2.0 0.14 1.66
4 1.6 / 1.8 0.16 1.34
2 1.3 / 1.8 0.11 0.97
4 1.6 / 2.0 0.23 1.75
2 1.1 / 2.3 0.12 1.05
4 1.1 / 2.5 0.12 1.04
TA50m10
S0: S3 S5
Peak
1.85 0.07 0.06
1.44 0.12 0.10
1.02 0.12 0.10
1.92 0.12 0.11
1.53 0.08 0.06
1.85 0.11 0.10
17/72
