The following I/O decode ranges are fixed to the LPC Bus:
Parts of these ranges are not available if a Super I/O is used on the carrier board. If a Super I/O is not implemented on the carrier board,
then all these ranges are available for customer use. If you require additional LPC Bus resources other than those mentioned above, or more
information about this subject, contact congatec technical support for assistance.
9.2

PCI Configuration Space Map

Table 9 PCI Configuration Space Map
Bus Number (hex)
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
Copyright © 2017 congatec AG
Device Number (hex) Function Number (hex) Device ID
00h 00h
02h 00h
0Dh 00h
0Dh 01h
0Dh 02h
0Dh 03h
0Eh 00h
0Fh 00h
0Fh 01h
0Fh 02h
012h 00h
013h 00h
013h 01h
013h 02h
013h 03h
014h 00h
015h 00h
015h 01h
016h 00h
2Eh - 2Fh
4Eh - 4Fh
200h - 20Fh
2F8h - 2FFh
3F8h - 3FFh
378h - 37Fh
778h - 77Fh
3F0h - 3F5h
3F7h, 60h, 62h, 64h, 66h
Description and Device ID
0x5AF0 Host Bridge
0x5A84 Graphics and Display
0x5A92 Primary to SideBand Bridge
0x5A94 PMC (Power Management Controller)
0x5A96 Fast SPI
0x5AEC Shared SRAM
0x5A98 HDA
0x5A9A Simple Communication Controller 0
0x5A9C Simple Communication Controller 1
0x5A9E Simple Communication Controller 2
0x5AE3 SATA
0x5AD8 PCIe - A0
0x5AD9 PCIe - A1
0x5ADA PCIe - A2
0x5ADB PCIe - A3
0x5AD6 PCIe -B0
0x5AA8 USB-Host (xHCI)
0x5AAA USB-Host (xDCI)
0x5AAC I2C 0
*2
TA50m10
*1
*1
*1
